[BKT-CP-003/GAL] Bike rack 003
The bike rack 003 is a very versatile product since its compact size allows it to cover the smallest possible public space when not in use. Its aesthetics blend into the urban environment and it has a rubber surface on its upper part that makes it soft in contact with our bicycle. This product is suitable for a capacity of 2 bicycles.
Descarga de recursos


Archivo Técnico PDF
Dibujo Tecnico CAD
Ficha de sustentabilidad

Specifications

Manufacturing Steel cycle port with vulcanized rubber
Finishes hot dip galvanized
Dimensions 30 cmx 20 cm x 92 cm
Color Galvanized
Author Industrial Design Registration No. 31398
Type Capacity 2 bikes

Croquis

Bike rack 003

Materiales.


Steel

The basic material used for the manufacture of most of the components of the products is steel of class 11373 (S235JR) or better quality. Tolerances are in accordance with ISO 2768-1 “m”, quality of imperfections in accordance with EN 25817. «C».

La mayoría de piezas de acero se procesan de la siguiente manera:

    CNC laser cutting

    CNC bending

    Galvanizing - different methods

    Degreasing by washing at 80oC - iron phosphating (corrosion protection)

    Pasivación acromática (limpieza con agua destilada)

    Secado a temperatura de 190oC durante 10-20 minutos

    Aplicación electrostática de pintura en polvo
Acabados metálicos

All our products go through a series of processes according to the type of material and use, in order to provide the highest quality and durability the highest quality and durability possible; the combination of these processes is a particular processes is a particular art achieved in years of experience, that only the right technology and raw material allow it.



The finishing method is according to to the model and part of the product:


Galvanizado en caliente

Metalización

Pintura Zinc

Galvanizado continuo

Electro-galvanizado

Pintura poliéster
